SOLENOID VALVE COIL PNEUMATIC TYPE

Pneumatic Solenoid Valve suitable for compressed water, air, gases, and low pressure oil. These coils are easy to assemble, corrosion resistant and efficient performance.

Pneumatic type Solenoid Valve Coil are mostly utilized in many industries to transform electrical signal into pneumatic functionalities. This kind of valve is highly required in various chemical and pharmacy industries to control the flow of fluids.

Technical Specfication

SR NO.	Solenoid Valve Coil Pneumatic Type	ID IN MM	OD IN MM	HT IN MM
1	Rotex Type Coil Size – I	14	42	42
2	Mercury Type Coil	13	32 x 32	42
3	Festo Mini Type Coil G-25 Type Coil & Similer	8 9,10	22 x 30 22 x 30	29 29
4	G.G. 3 Pin Type Coil	13	32 x 43	42
5	Compair 2 Pin Coil	15	40	31.5
6	Avcon Small 2 Pin Type Coil	16	40	33.5
7	Avcon Small 2 Pin Ob Coil	15.5	40	33
8	Avcon Big 2 Pin Type	18	39	41
9	Avcon Big 2 Pin Ob Type Coil	18	45	45
10	G-50 3 Pin Schrader Type Coil	13	31.5 x 33.5	37.5
11	3 Pin Rotex Type Coil	15.5	43	42
12	Advance Type Coil	T14 B17	42.5	42
13	Asco Wire Lead Type Coil Small	13.2	35	33
14	Asco Wire Lead Type Coil Big	18	41	40
15	Asco Pic Nut Type Coil	15	42	34
16	Madras Asco 2 Pin Type Coil Big	18	41	40
17	Madras Asco 2 Pin Type Coil Sm	15	42	32
18	Denfoss Type Coil- Wire Lead	18	42	42
19	Fdl Type Coil – Wire Lead	14.5	T42 B45	53
20	Sporlan Type Coil For Refrigeration	T5.5 B16.5	50	39

Standard Range Pneumatic Coil List With Dimensions

SR NO.	Pneumatic Coil List With Dimensions	ID IN MM	OD IN MM	HT IN MM
1	2 Pin coil Big black	12	34	28
2	2 Pin coil small black	12	26	28
3	2 Pin collar type coil	11	30	27
4	Mini coil 24 VDC	12	32	30
5	Round Ms casing coil	07	30	31
6	2 Pin H spade coil	11.5	24	26
7	2 Pin H class coil	11	40	25
8	Square MS casing molded coil	10	20 x 22	30
9	2 Lead wire Potted coil	4	11	12
10	Square molded coil	5.5	15	26
