Vibrator Coil is a device that combines two magnetic devices on the same iron-cored solenoid, it operate equally on both AC and DC Current. We manufacture various types of Vibrator coils that are used in various applications like Construction site, automobile industry, metal industry, electrical industry. These coils are precisely designed, easy to install and required low maintenance.
| Coils Name | A | B | C | D | E | F | Rest At 220 Volt |
|---|---|---|---|---|---|---|---|
| 100 AMP | 79 | 79 | - | 25 | - | 65 | 1150 |
| 200 AMP | 94 | 94 | - | 38 | - | 75 | 750 |
| Type | A | B | C | D | E | F | G | Sealed Pull In Kg | Max Lenght Of Stroke In MM |
|---|---|---|---|---|---|---|---|---|---|
| NE-8 | 103 | 127 | 115 | 40 | 75 | 100 | 45 | 10.5 | 37 |
| NE-9 | 130 | 153 | 125 | 50 | 105 | 125 | 38 | 22.5 | 40 |
| NE-10 SUSPEN- DED | A- | 58 | 45 | 8 | A- | A- | 75 | 1.4 | 8 |
| NE-12 | 45 | 61 | 61 | 10 | 63 | 77 | 37 | 3 | 18 |
| NE-15T | 58 | 70 | 73 | 14 | 36 | 55 | 27 | 4.5 | 25 |
| NE-15 | 58 | 70 | 73 | 25 | 36 | 55 | 27 | 3.5 | 25 |
| NE-16 | 34 | 41 | 49 | 17 | 31 | 39 | 19 | 1 | 12 |
| NE-17T | 34 | 49 | 43 | 19 | 42 | 53 | 28 | 1.4 | 10 |
| NE-18T | 41 | 52 | 50 | 27 | 54 | 65 | 27 | 27 | 15 |
| Coils Names | A | B | C | D | E | F | Rest At 230 Volt |
|---|---|---|---|---|---|---|---|
| Small Vibrator | 56 | 35 | 23 | 42 | 40 | 57 | 116 |
| Heavy Duty Vibrator | 76 | 41 | 25 | 57 | 53 | 76 | 50 |
